Description

The Titan 720W Pro LED from solution is a LED luminaire high-performance designed to maximize photosynthesis with an efficiency of up to 2,9 µmol J and a photon flux (PPF) of 2 µmol s‑¹.

This means more useful light per watt consumed and heavier harvests with reduced energy consumption.

Its full spectrum—broad-spectrum whites combined with deep 660nm reds—covers all phases of growing, from propagation to flowering, without the need to change lamps.

The Titan 6W Pro LED's 720-bar folding body unfolds in seconds, fits into narrow aisles, and makes it easy to store flat.

The integrated plug-and-play controller eliminates external power supplies and reduces cabling, while fanless passive cooling ensures quiet, maintenance-free operation.

With an IP65 rating, the LED Titan 720W Pro withstands the moisture, dust, and splashes typical of greenhouses or demanding indoor spaces.

For complete control, it features a 0‑10 V potentiometer with 25%, 50%, 75% and 100% steps, plus RJ12 ports for daisy‑chaining and connecting to external controllers.

Its 200‑277 V AC input range allows for integration into commercial installations and the electronics comply with CE and RoHS regulations.

On surfaces of 1,5-1,8 m² it offers outstanding light uniformity without hot spots, increasing both the quantity and quality of the harvest.

Titan 720W Pro LED Specifications

• Nominal power 720 W
• Efficacy Up to 2,9 µmol/J
• PPF 2 008 µmol/s
• Input voltage 200 – 277 V AC, 50/60 Hz
• Integrated regulation Potentiometer 0‑10 V (25%/50%/75%/100%) + RJ12 (daisy‑chain)
• Number of LED bars: 6
• Beam angle 120°
• Dimensiones (desplegado) 1 080 × 1 080 × 45 mm
• Dimensions (folded) 1 × 135 × 575 mm (box size)
• Net weight approx. 12,8 kg.
• Lifespan (hours): 60000
• Degree of protection IP65
• Working temperature –40 °C … 40 °C
• CE, RoHS Certifications
• Included components: Luminaire, 2 steel cables, 2 pulleys/ratchets, RJ12 cable, manual

Download Aura Pro 720W LED System Manual | Solux (PDF)
